3. Electricity - Electronics Laboratory

Petroleum/Chemical Engineering Program Formal Name Courses Layouts Max Capacity Assignable Area (Sq. m.)
Electricity -Electronics Lab Electricity -Electronics; Electrical Circuit Analysis Lab 24 60


Entrance


Lab layout


Power Supply, Data Acquisition Interface; Three phase circuit; 1-3 phase Transformers


AC Motor/Generator, DC Motor/Generator, R-L-C Loads


Power Supply, Three phase circuit; Data Acquisition Interface; R-L-C Loads


Electronic Devices, Osiloscop, Function Generators
